4. Install the:
a) Hard drive and optical drive module
b) HDD assembly
c) Front bezel
d) Side cover
5. Follow the procedure in After working inside your computer.
Intrusion switch
Removing intrusion switch
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a) Side cover
b) Front bezel
c) HDD assembly
d) Hard drive and optical drive module
e) Heat sink assembly
3. To remove the intrusion switch:
a) Disconnect the intrusion switch cable from the connector on the system board [1].
b) Slide the intrusion switch and lift it away from the system [2].
Removing and installing components
93
