Steps
1. Align the notch on the memory module with the tab on the memory-module slot.
2. Slide the memory module firmly into the slot at an angle and press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.
Next steps
1. Remove the graphics card
2. Install the side cover.
3. Follow the procedure in after working inside your computer.
Speaker
Removing the speaker
Prerequisites
NOTE:
Based on the configuration ordered the images may slightly vary from the actual system. The images are still
applicable to convey the service procedures accurately.
1. Follow the procedure in before working inside your computer.
2. Remove the side cover.
3. Remove the fan assembly (This applies to 35 W and 65 W configuration systems).
About this task
The following images indicate the location of the speaker and provide a visual representation of the removal procedure.
30
Removing and installing components
