Installing the Dell OptiPlex Micro Console with DVD-RW
Recommended Screws:
Screw Type
Used in
ST4 x 13 mm, Wooden screw Wooden table
1. Perform the following steps as shown in the illustration:
a. Loosen the screws that secure the cover to the optical drive console [1].
b. Slide and lift the cover upwards to remove it from the console [2].
