Installing the Hard Drive
1. Insert the hard drive into the hard-drive bracket.
2. Align and place the hard-drive assembly to its slot on the computer.
3. Install the cover.
4. Follow the procedures in After Working Inside Your Computer.
Removing the HDMI or DisplayPort Connector Board
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Perform the following steps as shown in the illustration:
a. Disconnect the cable from the HDMI or DisplayPort connector board [1].
b. Remove the screws to secure the HDMI or DisplayPort connector board to the base panel [2].
c. Slide and lift the HDMI or DisplayPort connector board away from the computer [3].
28
