Installing the Coin-Cell Battery
1. Place the coin-cell battery into its slot on the system board.
2. Press the coin-cell battery downward to secure it.
3. Install the:
a. HDMI board
b. hard drive
c. cover
4. Follow the procedures in After Working Inside Your Computer.
System Board Layout
The following image displays the system board layout of the computer.
1. processor socket
2. processor fan connector
