5. Route the USB cables through the cable management clip and connect them to the computer. Close
the cable management clip.
6. Perform the following steps as shown in the illustration:
a. Prepare the wooden table by installing screws for mounting the optical drive console.
b. Align the slots on the optical drive console with the screws on the table and slide the optical drive
console and lock it.
c. Tighten the screws to secure the optical drive console to the wooden table.
15
