Coin-cell battery
Removing the coin-cell battery
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
About this task
CAUTION: The computer contains a coin-cell battery and requires trained technicians for handling guidance.
NOTE: Removing the coin-cell battery resets the BIOS settings to default. It is recommended that you note the BIOS
settings before removing the coin-cell battery.
The following image(s) indicate the location of the coin-cell battery and provides a visual representation of the removal
procedure.
Figure 13. Removing the coin-cell battery
Steps
1. Push the coin-cell battery-release lever on the coin-cell battery socket to release the coin-cell battery out of the socket.
2. Lift the coin-cell battery from the coin-cell battery socket.
Installing the coin-cell battery
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
6
Coin-cell battery 35
