Steps
1. Place the display assembly on a clean and flat surface.
2. Place the palm-rest and keyboard assembly on the display assembly.
3. Rotate to close the left and right hinges.
4. Align the screw holes on the display hinges with the screw holes on the palm-rest and keyboard assembly.
5. Replace the two screws (M2.5x4.5) that secure the left display hinge to the palm-rest and keyboard assembly.
6. Replace the two screws (M2.5x4.5) that secure the right display hinge to the palm-rest and keyboard assembly.
7. Connect the display cable to the connector on the system board and close the latch.
8. Adhere the tape that secures the display-cable connector latch to the system board.
Next steps
1. Install the base cover for computers shipped with an aluminum chassis.
2. Follow the procedure in After working inside your computer.
Display bezel
Removing the display bezel for computers shipped with a plastic
chassis
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover for computers shipped with a plastic chassis.
3. Remove the M.2 2230 solid-state drive for computers shipped with a plastic chassis.
4. Remove the wireless card for computers shipped with a plastic chassis.
5. Remove the display assembly for computers shipped with a plastic chassis.
About this task
NOTE: The display-hinge caps are a part of the display bezel.
The following image indicates the location of the display bezel and provides a visual representation of the removal procedure.
