About your monitor | 13
Back view
7
1
2
3
6
5
4
Label Description Use
1 VESA mounting holes (100 mm
x 100 mm-behind attached
VESA cover)
Wall mount monitor using VESA-
compatible wall mount kit (100 mm x 100
mm).
2 Regulatory label Lists the regulatory approvals.
3 Stand release button Releases stand from the monitor.
4 Power On/Off button To turn the monitor on or off.
5 Joystick Use it to control the OSD menu.
For more information, see Operating the
Monitor.
6 Mac Address, Barcode, serial
number, and Service Tag label
Refer to this label if you need to contact Dell
for technical support. The Service Tag is an
unique alphanumeric identifier that enables
Dell service technicians to identify the
hardware components in your computer and
access warranty information.
7 Cable-management slot Use to organize cables by inserting them
through the slot.
