Dell P3424WEB User Manual

About your monitor | 9
• The monitor is designed with Dell Power Button Sync (DPBS) feature to control
PC system power state from monitor power button.*
• Premium Panel Exchange for peace of mind.
• Optimize eye comfort with a flicker-free screen and ComfortView Plus feature.
• This monitor uses low blue light panel. When the monitor is reset to factory
settings or default setting (Preset mode: Standard), it works in compliance with
TUV Rheinland (hardware solutions provider).
• Decreases the level of hazardous blue light emitted from the screen to make
viewing more comfortable for your eyes.
• The monitor adopts Flicker-Free technology, which clears the eye-visible flicker,
brings comfort viewing experience and prevents users from suffering eye strain
and fatigue.
• Certified for Microsoft Teams
®
and Zoom
®
.
• Certified for Windows Hello
®
(Face Authentication) and supports Microsoft
Cortana
®
.
• Additional customization using Dell Peripheral Manager/Dell Display Manager
(DDM) for Windows operating system and Dell Display and Peripheral Manager
(DDPM) for Mac operating system.
* Dell system that supports DPBS is listed in Dell website. DPBS function can be
enabled in OSD menu under Display.
WARNING: The possible long-term effects of blue light emission from the
monitor may cause damage to the eyes, which includes but is not limited
to eye fatigue and digital eyestrain. ComfortView Plus feature is designed
to reduce the amount of blue light emitted from the monitor to optimize
eye comfort.
Operating system compatibility
• Windows 10 Version 21H2 and Windows 11 Version 21H2*
• macOS 12.3.1*
*The operating system compatibility on Dell and Alienware branded monitors may
vary based on factors such as:
• Specific release date(s) when operating system versions, patches, or updates are
available.
• Specific release date(s) when Dell and Alienware branded monitor firmware,
software application, or driver updates are available on the Dell support website.

Dell P3424WEB Specifications

General

Color gamut	99 %
Pixel pitch	0.2325 x 0.2325 mm
Pixel density	109.68 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	34.14 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 90 kHz
Supported video modes	480p, 720p, 1080i, 1080p
Screen curvature rating	3800R
Viewable size, vertical	334.8 mm
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	86.71 cm
Viewable size, horizontal	799.8 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1080, 2560 x 1440, 3440 x 1440
Tilt angle range	-5 - 21 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDCP version	2.2
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B, USB Type-C
Number of upstream ports	2
USB Power Delivery up to	90 W
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50/60 Hz
Power consumption (max)	210 W
Power consumption (standby)	0.3 W
Power consumption (typical)	31.5 W
Megapixel	4 MP
RMS rated power	10 W
Package weight	15850 g
Cables included	AC, DisplayPort, USB Type-A to USB Type-B, USB Type-C to USB Type-C
DisplayPort cable length	1.8 m
Doesn't contain	Arsenic, PVC/BFR
Sustainability certificates	ENERGY STAR, RoHS
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Office
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Bezel width (top)	39.2 mm
Bezel width (side)	8.67 mm
Depth (with stand)	242.47 mm
Width (with stand)	815.65 mm
Height (with stand)	595.89 mm
Weight (with stand)	10830 g
Bezel width (bottom)	21.7 mm
Depth (without stand)	84.85 mm
Height (without stand)	419.99 mm
Weight (without stand)	7430 g
