44 | Setting up the monitor
Connecting the USB-C Cable (A to C) (Optional)
USB
USB Type-C
NOTE: This connection only data is available and no video. Need another
video connection for display.
NOTE: USB Type-A to Type-C cable is not the standard in-box accessory.
Connecting the USB Type-C cable (C to C)
USB Type-C
USB Type-C
The USB Type-C port on your monitor:
• Can be used as USB Type-C, DisplayPort 1.2 alternatively.
• Supports USB Power Delivery (PD), with profiles up to 90 W.
NOTE: Regardless of the power requirement/actual power consumption
of your laptop, or the remaining power runtime in your battery, the Dell
monitor is designed to supply power delivery of up to 90 W to your laptop.
Rated power (on laptops that have USB
Type-C with Power Delivery)
Maximum charging power
45 W 45 W
65 W 65 W
90 W 90 W
130 W Not supported
