Removing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1. Disconnect the speaker cable from the system board.
2. Peel off the tape that secures the speaker cable to the palm-rest and keyboard assembly.
3. Note the cable routing, and remove the speaker cable from the routing guides on the palm-rest and keyboard assembly.
4. Remove the speakers, along with the cable from the palm-rest and keyboard assembly.
22
Removing the speakers 45
