Removing the display cable
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the wireless card.
4. Remove the display assembly.
5. Follow the procedure from step 1 to step 3 in "Removing the display back-cover and antenna assembly".
6. Remove the camera.
Procedure
1. Disconnect the camera cable from the display panel.
2. Peel off the tape that secures the display cable to the display panel.
3. Open the latch, and disconnect the display cable.
4. Lift the display cable off the display panel.
38
66 Removing the display cable
