Replacing the display cable
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Slide the display cable into the connector and close the latch to secure the cable.
2. Adhere the cable tape that secures the display cable to the display panel.
3. Connect the camera cable to the display panel.
4. Adhere the camera cable on the display panel.
Post-requisites
1. Replace the camera.
2. Follow the procedure from step 3 to step 5 in "Replacing the display back-cover and antenna assembly".
3. Replace the display assembly.
4. Replace the wireless card.
5. Replace the battery.
6. Replace the base cover.
39
Replacing the display cable 67
