116 Installing System Components
Figure 3-19. Removing and Installing the Integrated Storage Controller Card
1 expansion card riser 1 2 SAS data cable connectors (2)
3 SAS data cables (2) 4 integrated storage controller card
5 alignment guides (2) 6 integrated storage controller card connector
6
1
4
5
2
3
book.book Page 116 Wednesday, February 17, 2010 6:17 PM
