78 Installing System Components
Hard Drives
All drives connect to the system board through the SAS/SATA backplane
board mounted on the front-chassis assembly. Hard drives are supplied in
hot-swappable drive carriers that fit in the hard-drive bays.
CAUTION: Before attempting to remove or install a drive while the system is
running, see the documentation for the SAS controller card to ensure that the host
adapter is configured correctly to support hot-swap drive removal and installation.
CAUTION: Do not turn off or reboot your system while the drive is being formatted.
Doing so can cause a drive failure.
NOTE: Use only drives that have been tested and approved for use with the
SAS/SATA backplane board.
When you format a hard drive, allow enough time for the formatting to be
completed. Be aware that high-capacity hard drives can take a number of
hours to format.
Removing a Hard-Drive Blank
CAUTION: To maintain proper system cooling, all empty hard-drive bays must
have drive blanks installed.
1
If installed, remove the front bezel
. See
"Removing the Front Bezel" on
page 75.
2
Grasp the front of the hard-drive blank, press the release button and slide
the blank out until it is free of the drive bay. See Figure 3-4.
book.book Page 78 Wednesday, February 17, 2010 6:17 PM
