Dell PowerEdge R650XS RD8NP User Manual

Figure 67. Riser 2b (SNAPI)
Figure 68. Riser 2c
NOTE: The expansion-card slots are not hot-swappable.
The following table provides guidelines for installing expansion cards to ensure proper cooling and mechanical fit. The expansion
cards with the highest priority should be installed first using the slot priority indicated. All the other expansion cards should be
installed in the card priority and slot priority order.
Table 31. Configuration 0: R1
Card type Slot priority Maximum number of cards
Dell Front PERC Integrated slot 1
Dell Serial port module (LP) 1 1
Mellanox (NIC: 200Gb) 1 1
Intel (NIC: 100Gb) 1 1
Installing and removing system components 73

Dell PowerEdge R650XS RD8NP Specifications

General

Memory Slots	16 DIMM slots
Form Factor	1U rack server
Processor	Up to two 3rd Generation Intel Xeon Scalable processors, with up to 32 cores per processor
Memory	Up to 1TB DDR4, 3200 MT/s
Storage	Up to 8 x 2.5" or 3.5" drives (SAS/SATA/NVMe)
RAID Support	PERC H755
Power Supply	800W
Network	1 x 1GbE OCP 3.0 card (optional)
PCIe Slots	Up to 3 PCIe Gen4 slots
