Dell PowerEdge T310 User Manual

Troubleshooting Your System 147
Troubleshooting Your System
Safety First—For You and Your System
CAUTION: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
with the product.
Troubleshooting System Startup Failure
If your system halts during startup prior to video imaging or LCD messaging,
especially after installing an operating system or reconfiguring your system’s
hardware, check for the following conditions.
• If you boot the system to the BIOS boot mode after installing an operating
system from the UEFI Boot Manager, the system will hang. The reverse is
also true. You must boot to the same boot mode in which you installed the
operating system. See "Using the System Setup Program and UEFI Boot
Manager" on page 57.
• Invalid memory configurations could cause the system to halt at startup
without any video output. See "Expansion Cards" on page 114.
For all other startup issues, note the LCD panel messages and any system
messages that appear onscreen. See "LCD Status Messages" on page 25 and
"System Messages" on page 39 for more information.
book.book Page 147 Wednesday, August 19, 2009 4:40 PM

Dell PowerEdge T310 Specifications

General

Tcase	72.7 °C
Bus type	DMI
Stepping	B1
FSB Parity	No
Processor code	SLBLJ
Processor cache	8 MB
Processor cores	4
Processor model	X3430
System bus rate	2.5 GT/s
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor codename	Lynnfield
Motherboard chipset	Intel® 3420
Processing Die size	296 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 4x4
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	36 bit
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
Optical drive type	DVD-RW
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Number of HDDs installed	-
Memory slots	6x DIMM
Internal memory	4 GB
Buffered memory type	Registered (buffered)
CD read speed	16 x
Graphics card	G200eW
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	2.0
Power supply	375 W
Compatible operating systems	Windows Small Business Server 2008, Essential Business Server 2008, Server 2008 Foundation R2, Server 2008 SP2, x86/x64, Server 2008 R2, x64, HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Chassis type	Tower
Processor ARK ID	42927
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	521 mm
Width	218 mm
Height	440 mm
