Dell PowerEdge T310 User Manual

Using the System Setup Program and UEFI Boot Manager 65
PCI IRQ Assignment Screen
Serial Communication Screen
Option Description
<PCIe device> Use the <+> and <-> keys to manually select an IRQ
for a given device, or select Default to allow the BIOS to
select an IRQ value at system startup.
Option Description
Serial Communication
(On without Console
Redirection default)
Options are On without Console Redirection, On with
Console Redirection via COM1, and Off.
Serial Port Address Specifies the address of the serial ports.
External Serial Connector
(Serial Device1 default)
Specifies whether Serial Device1, Serial Device2,
or Remote Access Device has access to the external
serial connector.
Failsafe Baud Rate
(115200 default)
Displays the failsafe baud rate used for console
redirection. This rate should not be adjusted.
Remote Terminal Type
(VT100/VT220 default)
Options are VT100/VT220 or ANSI.
Redirection After Boot
(Enabled default)
Enables or disables BIOS console redirection after the
operating system boots.
book.book Page 65 Wednesday, August 19, 2009 4:40 PM

Dell PowerEdge T310 Specifications

General

Tcase	72.7 °C
Bus type	DMI
Stepping	B1
FSB Parity	No
Processor code	SLBLJ
Processor cache	8 MB
Processor cores	4
Processor model	X3430
System bus rate	2.5 GT/s
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor codename	Lynnfield
Motherboard chipset	Intel® 3420
Processing Die size	296 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 4x4
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	36 bit
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
Optical drive type	DVD-RW
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Number of HDDs installed	-
Memory slots	6x DIMM
Internal memory	4 GB
Buffered memory type	Registered (buffered)
CD read speed	16 x
Graphics card	G200eW
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	2.0
Power supply	375 W
Compatible operating systems	Windows Small Business Server 2008, Essential Business Server 2008, Server 2008 Foundation R2, Server 2008 SP2, x86/x64, Server 2008 R2, x64, HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Chassis type	Tower
Processor ARK ID	42927
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	521 mm
Width	218 mm
Height	440 mm
