Dell PowerEdge T310 - Removing a Hot-Swap Hard Drive From a Hard-Drive Carrier

94 Installing System Components
Removing a Hot-Swap Hard Drive From a Hard-Drive Carrier
Remove the screws from the slide rails on the hard-drive carrier and separate
the hard drive from the carrier. See Figure 3-9.
Figure 3-9. Removing and Installing a Hot-Swap Hard Drive
1 hard drive 2 screws (4)
3 SAS/SATA screw hole 4 hard-drive carrier
1
4
2
3
