Jumpers and Connectors
173
SAS Backplane Board Connectors
Figure 6-2.
SAS Backp
lane Board Connectors
1
hard drive connectors 0–3
2
backplane power (BKPLN)
3
SAS A connector
1
front
2
3
back
