Adding and Replacing Parts 97
3
Turn the computer right-side up, and then open the display all the way (180 degrees) so that it rests on
your work surface.
NOTICE: To avoid damaging the hinge cover, do not lift the cover on both sides simultaneously.
4
Insert a scribe in the indent to lift the hinge cover on the right side.
5
Ease the hinge cover up, moving from right to left, and remove it.
6
To replace the hinge cover, insert the left edge of the cover into place.
7
Press from left to right until the cover snaps into place.
8
Close the display and turn the computer upside-down.
9
Replace the battery. See “Replacing the Battery” on page 38.
Keyboard
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product
Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as a connector on the back of the computer).
1
Follow the procedures in “Before You Begin” on page 83.
2
Remove the hinge cover. See “Hinge Cover” on page 96.
1 hinge cover 2 indent
1
2
