Removing and Installing components
Topics:
• Recommended tools
• Screw size list
• Motherboard layout
• Side cover
• Expansion card
• Coin cell battery
• Hard drive assembly
• Front Bezel
• Hard drive and optical drive module
• Optical drive
• Memory module
• Heat sink and fan
• Intrusion switch
• Power switch
• Processor
• M.2 PCIe Solid State Drive -SSD
• Intel Optane card
• SD card reader - optional
• Internal Antenna - optional
• External Antenna - optional
• M.2 2230 WLAN card - optional
• Power supply unit
• Speaker
• System fan
• System board
Recommended tools
The procedures in this document require the following tools:
• Phillips #0 screwdriver
• Phillips #1 screwdriver
• Philips #2 screwdriver
• Plastic scribe
• T-30 torx screwdriver
NOTE:
The #0 screw driver is for screws 0-1 and the #1 screw driver is for screws 2-4.
4
Removing and Installing components 17
