Dell Precision 3431 Small Form Factor - Speaker; Removing Speaker

7. Install the:
a) Hard drive and optical drive module
b) Front bezel
c) Side cover
8. Follow the procedure in After working inside your computer.
Speaker
Removing speaker
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a) Side cover
b) Front bezel
c) Hard drive and optical drive module
3. To remove the speaker:
a) Disconnect the speaker cable from the connector on the system board [1].
b) Press the release tab [2] and pull the speaker out from the system [3].
Removing and Installing components
79
