Dell Precision 3540 - Power-Adapter Port; Removing the DC-In Port

Next steps
1. Replace the battery.
2. Replace the base cover.
3. Replace the microSD card.
4. Follow the procedure in after working inside your computer.
Power-adapter port
Removing the DC-in port
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the microSD card.
3. Remove the base cover.
4. Remove the battery.
Steps
1. Remove the two (M2x5) screws that secure the Type-C bracket [1]
2. Lift the Type-C bracket away from the computer [2].
56
Disassembly and reassembly
