Specifications 131
Track Stick
X/Y position resolution
(graphics table mode) 250 count/sec @ 100 gf
Size protrudes 0.5 mm higher than surrounding
keycaps
Battery
Ty p e :
9-cell lithium-ion battery
85 WHr
6-cell lithium-ion battery
56 WHr
Dimensions:
Depth
77.2 mm (3.08 inches)
Height
20.0 mm (0.80 inch)
Width
187.03 mm (7.48 inches)
Weight:
9-cell lithium-ion battery
0.485 kg (1.07 lb) (typical)
6-cell lithium-ion battery
0.355 kg (0.783 lb) (typical)
Voltage 11.1 VDC
Operating time varies depending on operating conditions
and can be significantly reduced under
certain power-intensive conditions (see
"Battery Performance" on page 29 for more
information)
Life span (approximate) 500 discharge/charge cycles
Temperature range:
Operating
0° to 35°C (32° to 95°F)
Storage
–40° to 65°C (–40° to 149°F)
AC Adapter
Input voltage 100–240 VAC
Input current (maximum) 1.5 A
Input frequency 50–60 Hz
Output current 4.62 A
Output power 90 W
Rated output voltage 19.5 VDC
