Inside view — front
1. video-card heatsink
2. video card
3. I/O Board
4. processor heatsink
5. express card module
6. Unified Security Hub (USH) Board
7. secondary memory
8. wi-fi switch board
Removing the Secure Digital (SD) Card
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Press in on the SD card to release it from the computer. Slide the SD card out of the computer.
Installing the SD Card
1. Push in the SD card into its slot until it clicks into place.
2. Follow the procedures in
After Working Inside Your Computer.
