Table 32. Physical Dimension
Physical M4800 M6800
Height:
Touch
• Front: 36.1 mm (1.42
inches)
• Back: 40.2 mm (1.58
inches)
Non-touch
• Front: 32.9 mm (1.29
inches)
• Back: 36.7 mm (1.44
inches)
• Front: 33.1 mm (1.30
inches)
• Back: 37.2 mm (1.46
inches)
Width 376 mm (14.80 inches) 416.70 mm (16.40 inches)
Depth 256 mm (10.07 inches) 270.60 mm (10.65 inches)
Weight (Minimum) 2.89 kg (6.38 lb) 3.58 kg (7.89 lb)
Table 33. Environmental
Feature Specification
Temperature range:
Operating 0 °C to 40°C (32 °F to 104°F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative humidity (maximum):
Operating 10 % to 90 % (non-condensing)
Storage 5 % to 95 % (non-condensing)
Maximum vibration:
Operating 0.66 GRMS, 2 Hz - 600 Hz
Storage 1.3 GRMS, 2 Hz - 600 Hz
Maximum shock:
Operating 140 G, 2 ms
Non-operating 163 G, 2 ms
Altitude:
Storage 0 m to 10668 m (0 ft to 35,000 ft)
Airborne contaminant level G1 or lower as defined by ANSI/ISA-S71.04-1985
81
