About your monitor | 11
Monitor specifications
Model S2422HZ S2722DZ
Screen type Active matrix - TFT LCD
Panel type In-plane switching technology
Aspect ratio 16:9
Viewable image dimensions:
Diagonal 604.70 mm (23.80 in.) 684.70 mm (27.00 in.)
Active area:
Horizontal 527.0 4 mm (20.75 in.) 596.74 mm (23.49 in.)
Vertical 296.46 mm (11.67 in.) 335.66 mm (13.22 in.)
Area 156246.28 mm
2
(242.15 in.
2
) 200301.75 mm
2
(310.47 in.
2
)
Pixel pitch
0.2745(H) mm x 0.2745 (V) mm
0.2331 (H) mm x 0.2331 (V) mm
Pixel per inch (PPI)
92.56 108.79
Viewing angle:
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness 250 cd/m² (typical) 350 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Display screen
coating
Anti-glare treatment of the front polarizer (3H) hard coating
Backlight LED
Response time
(Gray to Gray)
8 ms (Normal mode)
5 ms (Fast mode)
4 ms (Extreme mode)
Color depth 16.7 million colors (6 bit+FRC) 16.7 million colors (8 bit)
Color gamut
1
99% sRGB with hardware low blue light
Connectivity •1 x DP 1.2 (HDCP1.4)
•1 x HDMI1 .4 (HDCP1.4)
•1 x USB-C (Alternate mode with DisplayPort 1.2, USB 3.2 Gen 1
upstream port, Power Delivery PD up to 65 W)
•1 x USB 3.2 Gen1 (5 Gbps) downstream with BC1.2 charging at
2A (maximum)
•1 x USB 3.2 downstream
•1 x 3.5 mm audio-out jack
