About the Printer | 15
About the Printer
Front and Rear Views
Front View
*
USB 2.0 host port (for the Print from USB feature)
1 Transfer Belt Unit 8 Toner Cartridges
2 Drum Cartridges 9 Front Cover
3 Waste Toner Box 10 Front USB Port
*
4 Right Side Cover 11 Control Panel
5 Tray 1 12 Output Tray Extension
6 Optional 550-Sheet Feeder (Tray 2) 13 Top Cover
7 Bypass Tray (Tray 5)
1
2
3
4567
8
109111213
