Dell S3840cdn - Rear View

16 | About the Printer
Rear View
*1
USB 2.0 host port (for Smart Card)
*2
USB 3.0 device port
1 Control Board 7 Power Inlet
2 Left Side Cover 8 Duplex Unit
3 Wireless Adapter Socket 9 2nd Belt Transfer Roller (2nd BTR)
4USB Port
*1
10 Fusing Unit
5USB Port
*2
11 Rear Cover
6 Ethernet Port
12
3
4
5
6
7
9
10
11
8
