Removing Options | 243
Removing the Optional Wireless Adapter
• When you remove the optional wireless adapter, be sure to turn off the printer, unplug the power
cable, and disconnect all cables from the back of the printer before starting these tasks.
1 Ensure that the printer is turned off.
2 Turn the screw on the left side cover counterclockwise to loosen it.
3 Slide the left side cover towards the back of the printer.
4 Open the left side cover completely.
To Next Page
