• Troubleshooting tools
S4810-ON system information
To view your system information; for example, the model, part number, serial number, and service tag, follow these steps.
1 Reboot your system and enter U-Boot mode.
2
Enter the sys_eeprom command.
Example of the sys_eeprom Command
dell_s4810_on-> sys_eeprom
TlvInfo Header:
Id String: TlvInfo
Version: 1
Total Length: 73
TLV Name Code Len Value
-------------------- ---- --- -----
MAC Addresses 0x2A 2 65
Base MAC Address 0x24 6 00:E0:0C:02:01:FD
Vendor Name 0x2D 4 Dell
Product Name 0x21 8 S4810-ON
Part Number 0x22 10 7590009602
Serial Number 0x23 13 HADL127B20077
Manufacturer 0x2B 1 1
Service Tag 0x2F 2 123A1B2
Label Revision 0x27 3 A00
CRC-32 0xFE 4 0x4AF6A929
Checksum is valid.
Boot processes
After the BIOS or U-Boot hardware verications, POST tests run to verify the CPU and memory prior to booting the system software.
After POST testing, there are three additional types of diagnostic tools you can use for testing your system.
• Manual diagnostic boot process — To run additional testing, manually download and run the EDA tool. The EDA tool reports and logs
pass/fail results.
• ONIE with EDA — EDA is installed; you do not have to manually download the tool. Select the diagnostic option at boot-up. You can
run this tool without a management interface.
• Autorun EDA — EDA is installed; you do not have to manually download the tool. Select the diagnostic option at boot-up. You can run
this tool without a management interface. The system always launches EDA in Quick Test mode to verify the hardware components
before loading the software. If there is a failure at boot-up, based on the EDA conguration, the software may or may not continue the
boot process.
POST
POST diagnostics veries system memory before the software loads. Test conguration parameters are saved in CMOS for the next boot-
up.
EDA, Quick Test Mode
Quick Test mode runs basic device access tests for the system hardware to verify that the device is active and responding.
In Quick Test mode, the EDA tool quickly tests if the hardware components are accessible. It conrms that the components respond to
read access and in some cases, simple write access. Tests are read-only and non-destructive (except the memtool command, which does
allow read/write operations).
ONIE diagnostics
