Fan
Dell™Studio1735/1737ServiceManual
Removing the Fan
Replacing the Fan
Removing the Fan
1. Follow the instructions in Before You Begin.
2. Follow the instructions in Removing the System Board.
3. Remove the screw that secures the fan to the computer base.
4. Lift the fan, along with the cable, off the computer.
Replacing the Fan
1. Place the fan, along with the cable, on the computer base.
2. Replace the screw that secures the fan to the computer base.
3. Follow the instructions Replacing the System Board.
Back to Contents Page
CAUTION: Before working inside your computer, follow the safety instructions that shipped with your computer.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface
(such as a connector on the back of the computer).
CAUTION: Before working inside your computer, follow the safety instructions that shipped with your computer.
NOTICE: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of your
computer's electronic components. You can do so by touching an unpainted metal surface.
NOTE: This procedure assumes that you have already removed the fan and are ready to replace it.
