1. Place the latch assembly in the channel on the computer base.
2. Using a small screwdriver, place the spring over the hook on the computer base.
3. Replace the three screws.
Ensure that the newly installed latch moves smoothly and freely when pushed and released.
4. Replace the charger board (see Replacing the Charger Board).
5. Replace the system board (see Replacing the System Board).
6. Replace the palm rest (see Replacing the Palm Rest).
7. Replace the hard drive (see Replacing the Hard Drive).
8. Replace the display assembly (see Replacing the Display Assembly).
9. Replace the base cover (see Replacing the Base Cover).
10. Replace the keyboard (see Replacing the Keyboard).
11. Replace the center control cover (see Replacing the Center Control Cover).
12. Slide the battery into the bay until it clicks into place.
Back to Contents Page
NOTICE: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
