 Wireless Local Area Network (WLAN) Card
Service Manual
Removing a WLAN Card
Replacing a WLAN Card

Your computer supports a WLAN card. If you ordered a WLAN card with your computer, the card is already installed.
Removing a WLAN Card

1. Follow the procedures in Before Working on Your Computer.

2. Turn the computer upside down.

3. Remove the hard drive (see Removing the Hard Drive).

4. Remove the M2 x 3-mm screw that secures the WLAN card.

5. Slide the WLAN card out of its system board connector at a 45-degree angle.

6. Disconnect the two antenna cables from the WLAN card.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer.
1
WLAN card
2
system board connector
3
M2 x 3-mm screw
4
antenna cables (2)
