Dell Vostro 1310 - Coin-Cell Battery

Back to Contents Page
 Coin-Cell Battery
Service Manual
Removing the Coin-Cell Battery
Replacing the Coin-Cell Battery
Removing the Coin-Cell Battery


1. Follow the procedures in Before Working on Your Computer.

2. Remove the hard drive (see Removing the Hard Drive).

3. Remove the WLAN card (see Removing a WLAN Card).

4. Remove the fan (see Removing the Fan).

5. Remove the hinge cover (see Removing the Hinge Cover).

6. Remove the keyboard (see Removing the Keyboard).

7. Remove the display assembly (see Removing the Display Assembly).

8. Remove the palm rest (see Removing the Palm Rest).

9. Disconnect the cable that secures the internal card with Bluetooth®wireless technology to the system board (see Removing the Card).

10. Remove the optical drive (see Removing the Optical Drive).

11. Remove the system board (see Removing the System Board Assembly).

12. Disconnect the coin-cell battery cable connector from the system board.

13. Lift the coin-cell battery from the system board.
Replacing the Coin-Cell Battery


CAUTION: Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer.
1
coin-cell battery cable connector
2
coin-cell battery
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer.
NOTE: This procedure assumes that you have completed the removal procedure first.
