1. Connect the coin-cell battery cable connector to the system board.
2. Position the coin-cell battery on the system board.
3. Replace the system board (see Replacing the System Board Assembly).
4. Replace the optical drive (see Replacing the Optical Drive).
5. Connect the cable that secures the internal card with Bluetooth wireless technology to the system board (see Replacing the Card).
6. Replace the palm rest (see Replacing the Palm Rest).
7. Replace the display assembly (see Replacing the Display Assembly).
8. Replace the keyboard (see Replacing the Keyboard).
9. Replace the hinge cover (see Replacing the Hinge Cover).
10. Replace the fan (see Replacing the Fan).
11. Replace the WLAN card (see Replacing a WLAN Card).
12. Replace the hard drive (see Replacing the Hard Drive).
