18 Setting Up and Using Your Computer
Back View of the Computer
1 power connector Insert the power cable.
2 voltage selector switch Used to select voltage rating.
3 power supply LED Indicates power availability for power supply.
4 back panel connectors Plug USB, audio, and other devices into the
appropriate connector. See "Back Panel Connectors"
on page 20 for more information.
1
2
3
4
6
5
7
book.book Page 18 Thursday, June 14, 2007 6:23 PM
