Removing and Installing Parts 143
Optical Drive
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions located in the Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from
the electrical outlet before removing the cover.
Removing an Optical Drive
1
Follow the procedures in "Before You Begin" on page 101.
2
Remove the computer cover (see "Removing the Computer Cover" on
page 103).
3
Remove the bezel (see "Removing the Bezel" on page 123).
4
Disconnect the optical drive data cable from the system board connector.
5
Disconnect the power cable and the optical drive data cable from the back
of the drive.
book.book Page 143 Thursday, June 14, 2007 6:23 PM
