c) memory
d) optical drive
e) hard drive
f) keyboard
g) palmrest
h) WLAN card
i) heat-sink fan
j) system board
NOTE: You do not need to remove the system board to remove the speaker, however you must disconnect the
speaker cable from the system board.
3. Lift the left and right speakers from the computer.
Installing the Speakers
1. Place the left and right speakers on the chassis.
2. Install the:
a) system board
b) heat-sink fan
c) WLAN card
d) palmrest
e) keyboard
f) hard drive
g) optical drive
h) memory
i) base cover
j) battery
3. Follow the procedures in After Working Inside Your Computer .
Removing the Processor
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the:
