Table 24. Screw list for computers with Energy Efficient Processors(continued)

Component Screw type Quantity

Hard drive M3x3.5 4

M.2 2230/2280 solid-state drive M2x3.5 1

I/O cover M3x5 2

Bottom cover M3x5 3

Retractable-camera assembly M3x5 4

Fan M3x5 3

I/O bracket M3x5 3

Heat sink Captive 5

System board M3x5 7

M3x12 1

Power-button and I/O board shield M3x5 3

Power-button and I/O board M3x5 2

Audio board shield M3x5 3

Audio board M3x5 2

Major components of OptiPlex All-in-One 7410

The following image shows the major components of OptiPlex All-in-One 7410.

NOTE: This is the major components for computers shipped with a High Performance processor.
