Steps
1. Align the notch on the memory module with the tab on the memory-module slot
2. Slide the memory module firmly into the slot at an angle and press down on the memory module down until it clicks into
place.
NOTE: If you do not hear the click, remove the memory module and reinstall it again.
NOTE: Repeat steps 1 to 2 for each memory module to be installed on your computer.
3. Close the DIMM door and press it into place, securing it.
Next steps
1. Install the back cover.
2. Install the stand.
3. Follow the procedure in After working inside your computer.
Removal and installation procedures for High Performance processors
49
