Procedure
1 Lift to release the graphics-card bracket from the chassis.
Figure 21. Removing the graphics-card bracket
1
graphics-card bracket 2 chassis
2 Press the releasing clip on the power-cable connectors and disconnect the
power cables from the graphics card.
71
