Replacing the power-button
module
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
GUID-C74A0244-4BF2-446E-89D8-13E5F748FB9D
Procedure
1 Route the cable through the slot on the top of the chassis.
2 Align the screw hole on the power-button module with the screw hole on the
chassis.
3 Replace the screw that secures the power-button module to the top chassis.
4 Route the power-button module cable through the routing guides on the chassis.
5 Connect the power-button module cable to the system board.
For more information, see “System-board components”.
GUID-055D5FE6-AB1C-4D02-B981-F61D4BA56B65
Post-requisites
1 Replace the front bezel.
2 Replace the top cover.
3 Replace the right-side cover.
