GUID-5B06BEBD-0365-4A39-AC01-7B04B931ACC7
Replacing the processor fan and
heat-sink assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
GUID-751E9076-6CE9-4899-9359-8002E8147C25
Procedure
CAUTION: If either the processor or the heat-sink assembly is replaced, use
the thermal grease provided in the kit to make sure that thermal
conductivity is achieved.
NOTE: The original thermal grease can be reused if the original processor
and heat-sink assembly are reinstalled together.
1 Place the processor fan and heat-sink assembly over the processor.
2 Align the captive screws on the processor fan heat-sink assembly with the screw
holes on the system board.
3 In a non-adjacent sequence, tighten the captive screws that secure the
processor fan and heat-sink assembly to the system board.
4 Connect the processor-fan cable to the system board.
For more information, see “System-board components.
GUID-36D1D9F7-BEFF-467E-8C1D-633BFF20E7F2
Post-requisites
1 Follow the procedure from step 9 to step 10 in “Replacing the power-supply
unit.
