Removing the top I/O-panel
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
GUID-A465C1B3-F96B-4F75-8D60-58E34ABC3EDE
Prerequisites
1 Remove the right-side cover.
2 Remove the front bezel.
3 Remove the top cover.
4 Follow the procedure from step 1 to step 2 in “Removing the power-supply unit”.
GUID-9BE7E456-655C-42A5-A99F-DC9307532001
Procedure
1 Disconnect the top I/O-panel cables from the system board.
For more information, see "System-board components”.
2 Note the I/O-panel cables routing and remove them from the routing guides next
to the system board on the chassis.
