Dell XY689 - Installing the Palmrest

b. battery
c. WLAN card
d. LED board
e. system fan
f. display assembly
g. SSD
h. memory
i. heat sink
j. system board
3. The palmrest can be removed after all other components have been disassembled.
Installing the palmrest
1. Align the palmrest into its slot on the computer chassis.
2. Install the:
a. system board
b. display assembly
c. system fan
d. LED board
e. SSD
f. heat sink
g. memory
h. WLAN card
i. battery
