18
14. THOROUGH CLEANING OF MILK CARAFE
VERY IMPORTANT
To ensure optimum results are obtained from
the Lattecrema system over time, clean the
milk carafe thoroughly on a regular basis.
Clean the milk carafe as described below:
1. Release the lid (E1)by turning clockwise: the reference
mark on the lid must be aligned with the symbol
(g. 18);
2. Now lift the lid (g. 19).
3. Pull out the milk intake tube (30).;
1
30 31
4. Turn the milk spout at right angles to the body and pull
until completely detached (g. 31);
5. Press the button (E5)to separate the connector (g. 32).
32
2
1
6. Wash in a dishwasher (recommended) or by hand as in-
dicated below:
• In a dishwasher: Rinse all the above components and
the milk container under hot running drinking water (at
least 40 °C), then place them in the top basket of the dish-
washer and run a wash programme at 50 °C, e.g. standard
ECO.
• By hand: Rinse all the components and the milk container
thoroughly with hot running drinking water (at least 40 °C)
to remove all visible milk residues, making certain to direct
the water through all the holes of the lid (g. 33). Next,
immerse all the components in a solution of hot drinking
water (at least 40° C) and washing up liquid for at least 30
minutes. Rinse all the components described above thor-
oughly under hot drinking water, rubbing each one individ-
ually between ngers and thumbs.
33 34
7. Rinse the milk carafe connector (E6) thoroughly (g. 34).
Take particular care to ensure that there are no milk res-
idues in the air channel (see enlargement) (g. 35):
free
the channel clean if need be
, using a toothpick;
35
8. Dry all the components with a clean dry cloth;
9. Push the connector fully home (g. 36 and 37): when
securely inserted, the connector can be detached only by
pressing the release button on the lid.
36 37
10. Reassemble all the lid components:
11. Close the carafe: ret the lid (the reference mark on the
lid must be aligned with the symbol marked on the
To Next Page
