12 Trigno Wireless System User’s Guide
TM
Power Supply
Trigno Systems are equipped with an isolated medical grade power
supply. The green power LED on the base station will illuminate
when power is connected to the Base Station. The power supply is
provided with interchangeable country-specific plug adapters. The
power supply can be conveniently stored in the Base Station storage
space when the system is not in use.
Figure 3. Trigno SC-P05 International Medical Power Supply with plug
adapter kit.
Trigno System are specifically designed and approved to
function only with the Power Supply provided. Power Supply
substitutions constitute a violation of the medical safety
approvals and will void the warranty.
If using a mains-powered PC then an additional isolation
transformer is required for medical compliance to IEC60601-1.
Refer to Appendix I for further details. No PC isolation is
required for operation on a battery-powered laptop.
